• Paint, solid
• Luggage rack side rails
• Bumpers, front and rear painted a single color
• Grille, chrome 7-slot
• Headlamps, dual composite halogen with automatic exterior lamp control
• Daytime Running Lamps
• Fog lamps, front, halogen
• Mirrors, outside power-adjustable, manual-folding
• Glass, Solar-Ray deep-tinted (all windows except light-tinted glass on windshield, driver- and front passenger-side glass)
• Wipers, front intermittent, variable, wiper/washer
• Wiper, rear wiper/washer
• License plate provision, front, includes bolts
• Body, driver-side-hinged swing gate with fixed glass

• Seats, front bucket, includes driver manual lumbar controls, adjustable outboard head restraints and map pockets on seatbacks
• Seat and interior trim, cloth
• Console, floor, multi-use (With 1SC and 1SD Preferred Equipment Group, Includes removable console tray.)
• Cupholders, 2 front and 1 rear
• Floor covering, color-keyed carpeting with Tufloor in rear cargo area
• Floor mats, ebony carpeted front, no accents
• Floor mats, ebony carpeted rear seat, no accents
• Floor mats, ebony carpeted cargo area, no accents
• Steering wheel, vinyl
• Tire Pressure Monitor
• Windows, power
• Door locks, power
• Remote Keyless Entry, with 2 transmitters and remote panic button
• OnStar, 1-year of Safe and Sound plan. Includes Automatic Notification of Air Bag Deployment, Stolen Vehicle Location Assistance, Emergency Services, Roadside Assistance, Remote Door Unlock, OnStar Vehicle Diagnostics, Hands-Free Calling, AccidentAssist, and Remote Horn & Lights. (OnStar services require vehicle electrical system (including battery), wireless service and GPS satellite signals to be available and operating for features to function properly. OnStar acts as a link to existing emergency service providers. OnStar Vehicle Diagnostics available on most 2004 MY and newer GM vehicles. Diagnostic capability varies by model. Visit onstar.com for system limitations and details.)
• Cruise control, electronic with set and resume speed
• Theft-deterrent system, vehicle, PASSlock II
• Retained accessory power
• Air conditioning, single-zone manual
• Defogger, rear-window
• Audio system, AM/FM stereo with CD player, seek-and-scan, digital clock, auto- tone control, speed-compensated volume, and TheftLock
• Audio system feature, 6-speaker system
• Glovebox, passenger-side
• Power outlets, 3 auxiliary with covers, 12-volt, includes 2 front and 1 in the rear cargo area
• Mirror, inside rearview auto-dimming with 8-point compass and outside temperature display
• Visors, driver and front passenger, includes vanity mirror on passenger side
• Assist handles, 5 total, 1 A-pillar mounted for front passenger, 2 B-pillar and 2 overhead-mounted for outboard rear seats
• Lighting, interior with front and interior dome, reading, cargo, instrument panel courtesy, door switches and illuminated entry

• Brakes, 4-wheel antilock, 4-wheel disc with a unique calibration for 4Lo
• Air bags, frontal, driver and right-front passenger with Passenger Sensing System (Always use safety belts and the correct child restraints for your childs age and size. Even in vehicles equipped with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See the vehicles Owners Manual and child safety seat instructions for more safety information.)
• Traction control
• StabiliTrak, Stability Control System
• Daytime Running Lamps
• Horn, single-note

ENGINE, 3.7L DOHC 5-CYLINDER MFI

• (STD)

• BVE
• CF5
• LLR
• M30
• UB0

• Vehicle
• Rear Door Type: Swing gate
• Mileage
• EPA Fuel Economy Est - City (MPG): 15
• EPA Fuel Economy Est - Hwy (MPG): 20
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 690
• Cold Cranking Amps @ 0° F (2nd): N/A
• Maximum Alternator Capacity (amps): 125
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3050
• Gross Axle Wt Rating - Rear (lbs): 3200
• Curb Weight - Front (lbs): 2585
• Curb Weight - Rear (lbs): 2115
• Gross Vehicle Weight Rating Cap (lbs): 5850
• Gross Combined Wt Rating (lbs): - TBD -
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 4500
• Dead Weight Hitch - Max Tongue Wt. (lbs): 450
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 4500
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 450
• Suspension
• Suspension Type - Front: Ind w/torsion bar
• Suspension Type - Rear: 5-link
• Spring Capacity - Front (lbs): 3050
• Spring Capacity - Rear (lbs): 3200
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-floating
• Axle Capacity - Front (lbs): 3050
• Axle Capacity - Rear (lbs): 3250
• Axle Ratio (:1) - Front: 4.56
• Axle Ratio (:1) - Rear: 4.56
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): 1.41
• Stabilizer Bar Diameter - Rear (in): 0.98
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.4 x 1.1
• Rear Brake Rotor Diam x Thickness (in): 12.3 x 0.5
• Tires
• Front Tire Order Code: QGC
• Rear Tire Order Code: QGC
• Spare Tire Order Code: QGC
• Front Tire Size: P265/75R16
• Rear Tire Size: P265/75R16
• Spare Tire Size: P265/75R16
• Front Tire Capacity (lbs): 2194
• Rear Tire Capacity (lbs): 2194
• Spare Tire Capacity (lbs): 2194
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x 7.5
• Rear Wheel Size (in): 16 x 7.5
• Spare Wheel Size (in): 16 x 7.5
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Aluminum
• Steering
• Steering Type: Pwr rack and pinion
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: 3.25
• Turning Diameter - Curb to Curb (ft): 37.0
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: - TBD -
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 23
• Fuel Tank Location: - TBD -
• Exterior Dimensions
• Wheelbase (in): 111.9
• Length, Overall w/rear bumper (in): 186.7
• Width, Max w/o mirrors (in): 74.7
• Height, Overall (in): 73.7
• Overhang, Front (in): - TBD -
• Overhang, Rear w/bumper (in): - TBD -
• Ground to Top of Load Floor (in): - TBD -
• Ground Clearance, Front (in): 9.1
• Ground Clearance, Rear (in): 9.1
• Rear Door Opening Height (in): - TBD -
• Rear Door Opening Width (in): - TBD -
• Step Up Height - Front (in): - TBD -
• Step Up Height - Side (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Console (in): - TBD -
• Cargo Area Length @ Floor to Seat 1 (in): - TBD -
• Cargo Area Length @ Floor to Seat 2 (in): - TBD -
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): - TBD -
• Cargo Box (Area) Height (in): - TBD -
• Cargo Volume to Seat 1 (ft³): - TBD -
• Cargo Volume to Seat 2 (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 5
• Front Head Room (in): 40.6
• Front Leg Room (in): 41.9
• Front Shoulder Room (in): 54.4
• Front Hip Room (in): 53.9
• Second Head Room (in): 39.9
• Second Leg Room (in): 35.0
• Second Shoulder Room (in): 53.5
• Second Hip Room (in): 53.5
• Summary
• Vehicle Name: HUMMER H3
• Body Style: 4 Door SUV
• Body Code: 111.9" WB
